All hello.
With you Maks
and today I want to offer you short video on changeover of the display in a boksmod of a fuchai 213.
Prehistory such is
– edge parts of the casing were unbent.
I don't know,
but most likely the casing is unbent by springs which accumulators nestle.
Our friends sorted modes and tried to return brute physical force on former places
end faces a mode and didn't note how realized clicking the display.
As a result we can watch a crack in glass.
There in interlayers of glass the thin loop lies,
when cracking glass the loop is torn.
In itself, modes operationally worked, only on the screen nothing is displayed.
Give, after all we will start changeover of the screen.
Initially I just model knife cut off a compound point.
Since the screen isn't suitable for further use any more,
I made it safely …
but if it is necessary just to remove the screen for certain procedures,
then this operation should be carried out accurately.
Then I apply fluxing agent,
I undertake a loop tweezers and I begin slowly slowly from beginning to end in process of heating
up to separate a display loop from a board.
Everything is ready.
Further I take the soldering dryer I put 100 degrees temperature
and I warm up the display to separate it from the casing,
and easily I give loading tweezers.
Here the display at us in hands. With it finished.
Now I align our contacts by means of fluxing agent and a soldering iron
I prepare a site under installation of the new display.
I recommend to begin installation of the new display with soldering of a loop,
it is so simpler to retain contacts in the necessary situation.
Here everything was soldered and just now it is possible to degrease surfaces and to put a double-side adhesive tape.
For simplification and the best patching it is possible to warm a few spliced surfaces too.
Everything, changeover of the display took place successfully,
and I already collected modes for its check.
According to users I will tell that many questions arise on screens of this device
and in order that video brought you a benefit,
I removed a card of voltage of the display after the relation to GND
and you can watch the picture with the table on the screen now.
All voltages are removed in case of the connected USB a wire.
If your indications differ also the screen not to shine,
then most likely there is a problem in a device board.
Under video I placed the reference to such screen, in the same place
it is possible to read its characteristics, it also approaches IPV 8 6 5
All thanks for your subscription of a likes and the comment,
don't forget that we have a public in VK – enter, are glad to all.
All good-bye, tasty vape and good …
